10KHz-200KHz 10w Laser Marking Machine Ultraviolet 220V Single Phase
Product Details:
| Brand Name: | ANZHI |
| Model Number: | UV-3W/UV-5W/UV-10W |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | 300 - 170000 USD |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100 pieces per month |
|
Detail Information |
|||
| Marking Depth: | 0.01-0.2mm | Laser Power: | 3W/5W/10W |
|---|---|---|---|
| Marking Area: | 110mm X 110mm | Working Temperature: | 10-35℃ |
| Laser Type: | UV Laser | Ccd Type: | High Resolution CCD |
| Software: | EZCAD | Control System: | PC Control |
| Working Voltage: | AC 220V/50Hz | Marking Content: | Text, Numbers, Symbols, Graphics, Barcodes, QR Codes |
| Cooling Method: | Air Cooling | Laser Wavelength: | 355nm |
| Marking Accuracy: | ±0.01mm | Marking Speed: | 7000mm/s |
| Highlight: | 10khz uv laser marking machine,10khz uv laser ccd marking machine,200khz uv laser marking machine |
||
Product Description
| Power Requirements: | 220V/ Single-phase/ 50Hz/ 10A | Machine Power: | 1KW |
|---|---|---|---|
| Equipment Weight: | 120kg For The Main Unit, 34kg For The Chiller (without Water). | Marking Line Speed: | ≤7000mm/s |
| Control System: | PC Control | Laser Power: | 3W/5W/10W |
| Laser Source: | UV Laser | Minimum Character: | 0.06mm |
| Highlight: |
200KHz 10w Laser Marking Machine,10KHz 10w Laser Marking Machine,Laser Marking Machine Ultraviolet |
||
Product Description
Optimal 1KW UV Laser Marking Machine with 100x100 Marking Range
Product Description:
Our UV Laser Graving Machine is a powerful tool for marking and engraving. It utilizes UltraViolet laser beams to produce high precision, permanent marks on almost any material. The machine is suitable for industrial markings, such as product labels, serial numbers, bar codes, and logos. It is a reliable and cost-effective solution for a wide range of applications.
The UV Laser Marking Machine offers a working distance of F160 Focal Length 192mm ± 5mm / F254 Focal Length 210mm ± 5mm. It is capable of producing marking line width of ≤0.01mm, and has a maximum laser power of 3W/5W/10W. It is powered by 220V/ Single-phase/ 50Hz/ 10A, and is controlled by a PC Control system.
The UltraViolet Laser Engraver is designed to be a reliable and cost-effective solution for industrial marking applications. It promises precise marks and permanence on almost any material, making it an ideal choice for product labeling, serial numbers, bar codes, and logos.
Features:
- Product Name: UV Laser Marking Machine
- Power requirements: 220V/ Single-phase/ 50Hz/ 10A
- Laser power: 3W/5W/10W
- Machine power: 1KW
- Model: UV-3W/UV-5W/UV-10W
- Marking line speed: ≤7000mm/s
- Product Features: UV Laser Graving Machine, UV Laser Marker, Ultraviolet Laser Scriber
Technical Parameters:
| Parameter | Value |
|---|---|
| Repetition frequency | 10-200KHz |
| Equipment weight | 120kg (main unit) 34kg (chiller, without water) |
| Marking line width | ≤0.01mm |
| Marking line speed | ≤7000mm/s |
| Minimum character | 0.06mm |
| Laser wavelength | 355nm |
| Laser power | 3W/5W/10W |
| Model | UV-3W/UV-5W/UV-10W |
| Laser Source | UV Laser |
| Equipment size | 530x780x1480mm (mainframe) 363x539x606mm (chiller) |
Applications:
ANZHI LASER UV Laser Marking Machine has many application scenarios and could be used in different industries. It is a reliable and high-performance product with advanced technology . The model numbers of this product are UV-3W, UV-5W and UV-10W and the minimum order quantity is 1 SET. The price is negotiable and the delivery time is 7-10 work days. It comes with a Plywood Box, and payment terms include T/T, L/C, D/A, D/P Western Union.MoneyGram,Paypal etc. It can supply up to 100 pieces per month. The equipment weight for the main unit is 120kg and for the chiller (without water) is 34kg. The power requirements are 220V/ Single-phase/ 50Hz/ 10A and the marking line width is ≤0.01mm. The repeatability is ±0.02mm and marking range is 100x100 (standard) 160x160 (optional). ANZHI LASER UV Laser Marking Machine is perfect for UV Laser Graving Machine, UltraViolet Laser Engraver, and Ultraviolet Laser Scriber.
Customization:
ANZHI LASER UV Laser Marking Machine is a professional grade laser marking tool, designed to engrave a variety of materials with great precision. It is equipped with a high-powered ultraviolet (UV) laser, which is capable of achieving a minimum repeatability of ±0.02mm. ANZHI LASER UV Laser Marking Machine is available in three models – UV-3W, UV-5W and UV-10W – with laser powers of 3W, 5W and 10W, respectively. The marking line width is ≤0.01mm.
- Brand Name: ANZHI LASER
- Model Number: UV-3W/UV-5W/UV-10W
- Place of Origin: Shenzhen, China
- Minimum Order Quantity: 1 SET
- Price: Negotiable
- Packaging Details: Plywood Box
- Delivery Time: 7-10 Work Day
- Payment Terms: T/T, L/C, D/A, D/P Western Union.MoneyGram,Paypal
- Supply Ability: 100 pieces per month
- Equipment weight: 120kg For The Main Unit, 34kg For The Chiller (without Water).
- Power requirements: 220V/ Single-phase/ 50Hz/ 10A
- Repeatability: ±0.02mm
- Laser power: 3W/5W/10W
- Marking line width: ≤0.01mm
Keywords: UV Laser Marker, Ultraviolet Laser Scriber, Ultraviolet Beam Engraver
Support and Services:
We provide comprehensive technical support and services for our UV Laser Marking Machines, including:
- Comprehensive installation and operational training
- Expert maintenance and repair services
- Technical support for troubleshooting and process optimization
- Timely replacement of consumable parts
- Engineering and technical consultation
Our technical team is ready to help you with any questions about our UV Laser Marking Machine. Contact us to get started today!
Packing and Shipping:
The UV Laser Marking Machine is shipped in a wooden box. The box contains the machine, instructions, and all accessories. The box is lined with foam to ensure the machine is not damaged during shipping.
When the machine is ready to be shipped, it is packed in the wooden box and wrapped in plastic to protect it from the elements. The box is then secured with straps to keep it in place during transport.
The UV Laser Marking Machine is shipped via a carrier service. The delivery time depends on the location and the service selected. All packages are insured.
